Antal (pakningsstørrelse 50 stk)
Total (23,84 kr. / stk.r)
1.192,00 kr.
ekskl. moms
Gratis fragt
30 dages returret
Højdepunkter og detaljer
Rækkeklemmer andre producenter
Vigtig information
Tekniske specifikationer
- Ledertværsnit, der kan tilsluttes / fintrådet / med terminalrør / maksimalt: 4 mm²
- ledertværsnit / fintrådet / med terminalrør bearbejdning / minimalt: 0.2 mm²
- antal kontaktpunkter / pr. klemplan: 2
- fastgørelsesskinner: 35 mm
- brændbarhedsklasse iht. UL 94: V0
- højde / ved montering af meget lav monteringsmetode: 46,3 mm
- klemmemål: 6,2 mm
- materiale/isolerende element: Termoplast
- position / tilslutningsklemme: Øverst
- produktkomponent / nødvendig / afslutningsplade: Ja
- omgivelsestemperatur / under drift / maksimalt: 55 °C.
- Emballage-type
Piece
- Produkttype
PE-gennemgangsklemme
- Særlige kendetegn:
sikker at røre ved
- Tilslutning
Indstiks-klemme
- Tværsnit fleksibel (min. )
0.2 mm²
- Tværsnit fleksibel (maks.)
4 mm²
- Tværsnit fast (min. )
0.2 mm²
- Tværsnit fast (maks.)
6 mm²
- Klemmebredde
6.2 mm
- Rækkeantal
1
- Producentfarve
Grøn-gul
- Afisoleringslængde (max.)
12 mm
- Produc.-delnr.
8WH60010CG07
- Indhold
50 stk
- Type
8WH6001-0CG07
- H
46.3 mm
- L
66 mm
- RoHS-godkendt
Ja
- Vægt
13 g
- Brændbarhedsklasse
V0
- Farve tilslutningselement
Grøn-gul
- Isoleringsmateriale
Termoplast
DIN rail (top hat rail) 35 mm
Other
6.15
65.95 mm
42.5 mm
66 m
V0
6.2 mm
46.3 mm
TRUE
Other
Other
1
2
Other
- UKCA
Ikke relevant
Dokumenter og downloads
Datablad
Datablad 2263973 Siemens 8WH60010CG07 PE-gennemgangsklemme 6.2 mm Indstiks-klemme Grøn-gul 50 stk Piece
Instruktioner for brug og sikkerhed
Instruktioner for brug og sikkerhed 2263973 Siemens 8WH60010CG07 PE-gennemgangsklemme 6.2 mm Indstiks-klemme Grøn-gul 50 stk Piece
Beskrivelse
PE-INSTA through-type terminal 4 mm2, 6.2 mm wide green-yellow Terminal block connection technology for various industrial applications and modern building installation from Siemens. Regardless of whether you decide on the screw-type, spring-loaded, push-in or quick connection: All of the connection technologies can be freely combined. The labeling and test accessories are standardized and can be used interchangeably. Many applications can be implemented in industry, functional and residential buildings with the terminal blocks from SIEMENS. This gives you access to the right connection technology for every connection system. Key features of the Siemens row terminals: 1. Permanently safe contact. 2. Easy to disconnect connection of electrical connections such as cables and wires. 3. Implementation of a large number of applications. 4. User-friendly and easy installation and connection technology. 5. Comprehensive and standardized accessories. 6. Reliable safety during installation with standard touch protection. 7. Optimized technology for your safety - only from Siemens.
tilbehør
(*Alle priser er ekskl. moms)Det nødvendige tilbehør er nødvendigt for at kunne bruge den beskrevne vare
